48V5KW

72V4KW

電池

BATTERY

鉛酸電池，48V150AH（9.6度）Lithium iron phosphate battery, Guosheng 48V200AH (9.6 KWH)

磷酸鐵鋰電池，72V140AH（10度）Lithium iron phosphate battery, Guosheng 72V140AH (10KWH)

電機                    MOTOR

馬勒,48V5KW交流

MAHLE 48V5KW A/C

馬勒,72V4KW交流

MAHLE 72V4KW A/C

控制器總成                     CONTROLLER

ACMII CURTIS    48C350AH

柯蒂斯    48C350AH

ACMII CURTIS    72C450AH

柯蒂斯嘉晨    72C450AH

DC-DC 轉換器總成

DC INVERTOR

CURTIS    350A

柯蒂斯 350A

CURTIS    450A

柯蒂斯 450A

后橋總成

rear axle assembly

零越，端面距958.8mm,板簧距660.3mm,圓法蘭，19齒，剎車盤直徑160mm，分布圓為4-φ101.6mm                          Lingyue Brand, end face distance 958.8mm, leaf spring distance   660.3mm, round flange, 19 teeth, brake disc diameter 160mm, distribution   circle 4-φ101.6mm

制動系統                 Brake sysytem

油剎、前碟后鼓                                                     Oil brake, front disc and rear drum

底盤材質

高強度碳鋼焊接+酸洗磷化+噴塑

懸掛系統                Suspension system

A字臂前獨立懸掛；后縱置板簧+阻尼器                          Front A arm independent suspension; rear longitudinal leaf spring +   damper

儀表臺                         Dashband

仿皮紋多功能汽車儀表臺                                              Multifunctional car dashboard

功能開關function switch

高級翹板開關Advanced Rocker Switches

USB系統USB system

USB2.0、3.0，支持U盤外接輸入音頻MP3、視頻等USB2.0,   3.0, support U disk external input audio MP3, video, etc.

點煙器插座

cigarette lighter socket

12V電源輸出

12V power output

中控顯示console display

10.1寸多媒體大屏；lINUX系統                            10.1-inch multimedia screen; LINUX system

中控屏功能                Central control screen   function

車輛檢測功能（車速、電量、電壓等）                          Vehicle detection   function (vehicle speed, power, voltage, etc.)

多媒體功能（通信錄、收音機、手機藍牙互聯及投屏、視頻、音樂、多國語言等）

音響系統                   sound system

Hasda汽車音響*2                                      Hasda   Car Audio*2

杯座                        cup holder

左右可抽拔式杯座各兩個                                       Two   removable cup holders on the left and right

儲物箱                     storage box

隱藏式儲物箱左右各一個，帶鑰匙鎖開合式面板                    Hidden storage   compartments, one left and one left, with key lock opening and closing panels

中控置物                    central storage

斜坡式置物格（可加球座及無線充電系統）                   Slope storage compartment   (can add tee and wireless charging system

前大燈                       Headlight

近光、遠光、轉向、帶日間行車燈功能                           Low beam, high   beam, steering, with daytime running lights

后大燈                     Taillight

轉向、剎車Steering, Braking

輪胎、輪轂                       tires, Hub Rim

205-40-14；235-30-14

左右后視鏡

帶電子轉向燈

安全帶                 safety seatbelt

twin point MG    steel toughed springs

座椅坐墊Seat and Cushion

一體成型仿皮座椅                                      Synthetic leather   seat

翻轉式折疊座椅flip-flops

底座材料（PP工程塑料）；一體成型仿皮座椅+儲物冰箱                                        Synthetic leather seat flip-flops

中網 Front Grill

按客人需求定做Customized as per customer's   design

車輛尺寸Vehicle Size

3855*1150*2000
